Key Features
- 24-Port Data input
- 24-Port PoE (Data + Power) output
• 1x10/100Base-TX management port with auto MDI / MDI-X feature
PoE
• Complies with IEEE 802.3af Power over Ethernet Mid-Span PSE
• Up to 24 IEEE 802.3af devices powered
• Supports PoE power up to 15.4 Watts for each PoE ports
• Automatically detect powered device (PD)
• Circuit protection prevent power interference between ports
• Remote power feeding up to 100m
PoE Management
• Total PoE power budget control
• Per port PoE function Enable/Disable
• PoE port power feeding priority
• Per PoE port power limit
• PD classification detection
• PoE Power Schedule
• Over Temperature Protection
Management
• Web interface for remote management
• Supports Network Time Protocol
• Firmware upgrade through Web interface
• PLANET Smart Discovery utility automatically finds PLANET devices on the network
• SNMP Trap for alarm notification of events
Hardware
• 19-inch rack mountable; 1U height
• Reset button for default setting and system reboot
• LED indicators for PoE ready, PoE activity, FAN Alert and Power Alert
