Conductor Type: Solid/Stranded
Number of Positions: 8
Keyed: No

Contact Base Material: Phosphor bronze
Contact Mating Area Plating Material: Gold
Contact Mating Area Plating Thickness: 1.27 µm
Number of Contacts Loaded: 8
Cable Jacket Outside Diameter Range: 5,1 mm
Conductor Outside Diameter: 0.86–0.99 mm
Conductor Wire Size: 26–24 AWG

Cable Type: Round, shielded
Performance Category: Category 5
Connector Style: Plug
Jack Type: RJ45
Latch Style: Standard
Product Type: Connector
Shielded: Yes
