Construction Materials
Construction Type Non-armored
Center Conductor Material Copper-clad steel wire
Corrosion Protection Water blocking gel
Dielectric Material Foam PE
Jacket Material PE
Shield (Braid) Coverage 60 %
Shield (Braid) Gauge 34 AWG
Shield (Braid) Material Aluminum
Shield (Tape) Material Aluminum/Poly, bonded
Dimensions
Cable Length 305 m | 1000 ft
Cable Weight 48.00 lb/kft
Diameter Over Center Conductor 1.6281 mm per 1 strand
Diameter Over Dielectric 7.1120 mm
Diameter Over Jacket 10.033 mm
Diameter Over Jacket Tolerance ±0.006 in
Diameter Over Shield (Tape) 7.925 mm
Jacket Thickness 1.016 mm
Jacket Thickness, minimum spot 0.813 mm
Electrical Specifications
Capacitance 53.1 pF/m | 16.2 pF/ft
Characteristic Impedance 75 ohm
Characteristic Impedance Tolerance ±3 ohm
Conductor dc Resistance 11.00 ohms/kft
Dielectric Strength, conductor to shield 4000 Vdc
Jacket Spark Test Voltage 4000 Vac
Nominal Velocity of Propagation (NVP) 82 %
Shield dc Resistance 6.90 ohms/kft
Structural Return Loss 15 dB @ 2200–3000 MHz | 18 dB @ 1000–2200 MHz | 20 dB @ 5–1000 MHz
Structural Return Loss Test Method 100% Swept Tested
Environmental Specifications
Environmental Space Buried
General Specifications
Application Satellite
Cable Type Series 11
Jacket Color Black
Mechanical Specifications
Minimum Bend Radius, loaded 20 times
Minimum Bend Radius, unloaded 10 times
Electrical Performance
Frequency
Attenuation (dB/100 ft)
1 MHz 0.17
10 MHz 0.45
50 MHz 0.89
100 MHz 1.21
200 MHz 1.68
400 MHz 2.37
700 MHz 3.27
900 MHz 3.77
1000 MHz 3.95
1200 MHz 4.46
1450 MHz 5.08
1800 MHz 5.58
2200 MHz 6.29
2500 MHz 6.79
3000 MHz 7.58
ECCN.NO EAR99
