Interface

2 RJ45 interfaces
1-port Data + Power output
1-port Data input
1 DC 52~56V input power socket
1 PoE mode (standard/legacy and force) DIP switch


Power over Ethernet

Complies with IEEE 802.3at/bt PoE end-span/mid-span PSE
Supports PoE power up to 95 watts for PoE port
Auto-detection of PoE IEEE 802.3af/at/bt equipment and devices from being damaged by incorrect installation
Monitors the status of the total PoE usage in real time
Remote power feeding up to 100m
Auto-detection of DC input voltage


Hardware

All-in-one compact size design
LED indicators for Power LED, PoE-in-Use LED, Legacy LED and PoE Usage LED
Wall-mount design
Metal case
Supports 6KV DC Ethernet ESD protection
